Features:
1. Ultra high DC precision

    Low offset voltage: typical value ≤ 100 μ V (e.g. OP07 is 10 μ V, ADA4528-1 is as low as 300nV).

    Low misalignment temperature drift: usually<1 μ V/℃, with stable accuracy over a wide temperature range.

    High Common Mode Rejection Ratio (CMRR):>100dB (such as 120dB for OPA211), effectively suppressing common mode noise.

    High open-loop gain (AVOL):>120dB, excellent amplification linearity.

2. Extremely low noise characteristics

    The voltage noise density is as low as a few nV/√ Hz (such as AD8676 with a peak to peak value of 0.1 μ V @ 0.1-10Hz), making it suitable for amplifying weak signals at the microvolt level.

3. Wide working range

    Wide power supply voltage: supports single power supply (5V~36V) or dual power supply (± 2.5V~± 18V).

    Wide temperature range: industrial grade -40 ℃~+125 ℃, suitable for harsh environments.

4. Universal and easy-to-use

    It can work in various modes such as linear amplification, active filtering, voltage following, comparator, etc.

    Most models support rail to rail input/output, fully utilizing the dynamic range of the power supply.

5. High stability

    Internal frequency compensation, no need for external compensation components, and less prone to self excitation.

    High Power Supply Rejection Ratio (PSRR) reduces the impact of power ripple.

Applications：
1. Precision instruments and meters

    Data acquisition system: Pre amplification of sensor signals to improve ADC measurement accuracy.

    Digital multimeter and oscilloscope: ensure the accuracy of voltage and current measurement.

    Strain bridge/bridge amplifier: used for pressure and weighing sensors (such as electronic scales).

2. Medical electronic devices

    Biological signal acquisition: pre amplification of electrocardiogram (ECG) and electroencephalogram (EEG).

    Medical testing equipment: blood analyzer, ultrasound equipment signal conditioning.

3. Industrial Automation and Control

    Industrial transmitters: temperature, flow, and liquid level sensor signal amplification.

    High side current detection: current monitoring in motor drive and power management.

    PID controller: constitutes a proportional integral derivative control loop.

4. High end audio and communication

    Hi Fi audio preamplifier: low distortion, low noise, improves sound quality.

    Precision filter: Signal filtering and anti-interference processing in communication equipment.
