Features:
1. Wide power supply voltage range
Typical: 4.5V~36V (single)/± 2.25V~± 18V (double)
High end: 2.7V~40V, ± 5V~± 50V, ± 110V (220V single power supply)
Compatible with 12V/24V industrial bus, automotive 12V/24V, and high-voltage instruments.
2. Excellent DC accuracy
Low offset voltage: typical ± 0.2~3mV (high-end can reach ± 30 μ V)
Low temperature drift: ± 0.25~2 μ V/℃
High Common Mode Rejection Ratio (CMRR): 100-160dB, suppresses common mode interference
3. Good dynamic performance
Squeezing rate (SR): 10~74V/μ s, fast response to large signals
Unit gain bandwidth (GBW): 1-52MHz
Fast overload recovery:<1 μ s
4. High stability and reliability
Wide temperature range: -40 ℃~+125 ℃
High PSRR: 110~146dB, resistant to power ripple
ESD protection: 2~4kV, short circuit protection, phase reversal protection
5. Diverse packaging options
SOT-23, SOIC-8, TSSOP-14, DFN, etc., available in single/dual/four channels
Applications：
1. Industrial Automation and Sensors
Pressure/flow/liquid level sensor signal amplification
PLC analog I/O, 4-20mA current loop, high side current detection
Industrial active filtering (filtering out 50/60Hz interference)
2. Power Supply and Power Electronics
Switching power supply/inverter feedback loop
UPS、 Server power and battery management system (BMS)
High voltage linear regulator, overvoltage/overcurrent protection
3. Automotive Electronics
Vehicle mounted 24V system, motor drive control
Car lights/LED drivers, ECU signal conditioning
Compliant with AEC-Q100
4. Testing, Measurement, and Instruments
Data acquisition (DAQ), oscilloscope front-end, high-precision ADC driver
High voltage signal source, piezoelectric ceramic drive, precision current/voltage meter
