Features:
1. Extremely fast response speed: response time * *<1ns * * (sub nanosecond level), can effectively suppress nanosecond and picosecond level transient interference.

2. Precise clamping voltage: Once turned on, the voltage can be accurately limited to a safe clamping voltage, with low residual voltage and good protection effect.

3. Extremely low leakage current: Under normal conditions, the leakage current is at the microampere level, with low power consumption and no interference with the signal.

4. Small size and high power: Surface mount packaging can absorb transient pulse power of hundreds to several kilowatts.

5. High reliability and infinite lifespan: It belongs to non breakdown protection, automatically restores high resistance state after overvoltage disappears, and can be reused.

6. Low cost, easy to integrate: suitable for large-scale application in various electronic devices.

Applications：
1. Interface protection

    Communication interfaces: USB, HDMI, Ethernet, RS-232/485, CAN bus, anti-static (ESD) and surge protection.

    Power interface: DC/DC power input and output terminals, designed to prevent power grid surges and sudden load drops.

2. Consumer electronics

    Anti static protection for charging ports, headphone jack, SIM card slot, and other I/O ports of mobile phones, computers, and tablets.

3. Automotive Electronics

    Protect the onboard ECU, sensors, and headlight circuits to prevent back electromotive force during engine start-up and relay switching.

4. Industrial control

    PLC、 Inverter, servo drive, transient high voltage during motor start stop and inductive load disconnection.
